Family rides

      Family Rides: 34 Models from 6 to 36 Seats

      This is the widest category in the outdoor range. It covers self-control rides where the passenger controls height, flying car variants, jumping and bouncing rides, and themed pieces such as the Christmas tree and samba balloon. Capacities run from 6 seats to 36, and most models fit a footprint between 5 m and 16 m across.

      Representative Models

      ModelModel No.CapacityHeightPowerCover area
      F1 Flying CarYTCN-5FR-058P3 m3.2 kW6 × 9 m
      Jumping FrogYTCN-5FR-166P8.5 m12 kW6 m diameter
      Water Spray Flying CarYTCN-5FR-0812P3 m4 kW6.8 m diameter
      Bee Pedal BikeYTCN-5FR-3212P—7 kW / 380 V5.2 m diameter
      UFO Flying CarYTCN-5FR-0213P3 m3.2 kW6 × 9 m
      Self-Control AirplaneYTCN-5FR-0116P6.9 m14 kW11 m diameter
      Jumping KangarooYTCN-5FR-0616P3 m3 kW8 m diameter
      Shark IslandYTCN-5FR-2224P4.2 m15 kW16 m diameter
      Samba BalloonYTCN-5FR-3432P—11 kW10 m diameter
      Christmas TreeYTCN-5FR-3732P—26 kW12.6 m diameter

      Two Sub-Groups

      Self-control rides — the passenger raises and lowers their own car with a button. These run at low height (3–6.9 m) and suit family parks where parents ride with young children. The Self-Control Airplane, Self-Control Wings and Self-Control Bee are all in this group at 11–14 kW.

      Flying car variants — the car follows a fixed path with no passenger control. UFO Flying Car and F1 Flying Car share a 6 × 9 m footprint and can run on 220 V or 380 V, which makes them usable in venues without three-phase supply.

      Choosing by Capacity

      Under 16 seats the ride usually fits inside a 6–9 m footprint and can be installed on a paved surface — this is the common choice for mall rooftops and hotel grounds. From 24 seats up, the cover area grows past 10 m and the power draw passes 11 kW, which means a dedicated position and a check on the site's supply.

      Related

      Swing rides · Carousels · Ferris wheels · Christmas rides · Family ride videos

      Questions buyers ask about family rides

      What power supply do these need?

      Drive power runs 3 kW to 26 kW across the 35 models. The smaller units are quoted at 220/380 V and the larger ones at 380 V.

      How much space does a family ride take?

      Footprints run from 6 m to 16 m, and the smallest units are quoted at a 6 m diameter, so a mall floor plan can be checked quickly.

      How many passengers per cycle?

      Six to thirty-two. Sixteen seats is the most common figure in this group, with 12, 18 and 24 seat versions around it.

      What does a unit weigh?

      Model weights run from 1,500 kg to 6,000 kg, which is the figure freight forwarders ask for first when quoting a container.
